VC4060PD Insulation Multimeter
VC4060PD Insulation + Multimeter, 100V/2GΩ-2500V/50GΩ, PI/DAR, True RMS test, NCV test, Data hold, Backlight, Torch lighting functions.
|
Range |
Basic accuracy |
|
|
±(5.0%+5) |
||
|
DC Voltage |
6V/60V/600V/1000V |
±(0.4%+1) |
|
AC Voltage |
6V/60V/750V |
±(0.5%+2) |
|
Resistance |
600Ω/600kΩ/6MΩ/60MΩ |
±(2.0%+5) |
|
Capacitance |
1nF/10nF/100nF/1μF/10μF/100μF /1mF/10mF/100mF |
±(2.0%+5) |
|
Frequency |
10Hz/100Hz/1kHz/20kHz/200kHz |
±1.0% |
Special function:
|
VC4060PD |
|
|
Max. display |
6000 |
|
Operation method |
Manual/Auto range |
|
Measuring time selecting |
|
|
PI/DAR indication |
√ |
|
True RMS, NCV, REL, Diode and Continuity test |
√ |
|
Data hold |
√ |
|
Backlight display |
√ |
|
AC frequency response |
40Hz~1kHz |
|
Auto power off |
Approx.15minutes |
|
Low battery indication |
Approx. less than 7.6V |
|
Sampling rate |
2times/s |
|
LCD size |
65×40mm |
|
Power supply |
9V (6x1.5V AA) |
|
Power consumption |
Max. 5W, standby mode is less then100uW |
|
Safety level |
CAT. III 600V |
General Info:
|
Orange holster and Grey device |
|
|
Weight |
480g (including battery) |
|
Meter size |
200X92X50mm |
|
Packaging style |
Gift box |
